Audi Q7 e-tron P33E8 and Won’t Charge: The Lock Pin Was Not the Failed Part
P33E8: The Lock Pin Was Working
Each time this Audi Q7 e-tron was plugged in, the connector lock tried three times and the inlet turned red. The noise made the latch an obvious suspect. Yet the pin reached its positions. The failed part was the onboard charger, which interpreted the lock-position voltage incorrectly and therefore refused to continue the AC charging handshake.
For low-voltage portions explicitly identified by Audi, a scope-capable meter such as the AUTOOL DM303 can support control-pilot, proximity, or lock-position checks outside the high-voltage boundary. DM303 can support accessible low-voltage control-pilot, proximity or lock-position checks only where Audi procedures and isolation rules permit; it cannot probe high voltage, certify EV safety or conclude that the onboard charger failed from latch noise alone.
Read this as a plug-in timeline, not as a parts list. Mode 2 and Mode 3 both failed, P33E8 was saved, physical pin movement was compared with reported state, and a real charge session—not an erased warning—proved the replacement onboard charger.
Quick answer: The plug lock moved, but the onboard charger read its position incorrectly. Comparing physical position with reported voltage justified OBC replacement and restored Mode 2/3 charging.

In this guide
- Rule out the cable and charge point without opening the car
- Record the three lock attempts and inlet light
- Map proximity, control pilot and lock position
- Prove the pin moves before replacing the latch
- Compare actual position with the OBC reading
- Keep low-voltage measurement outside the high-voltage zone
- Replace and commission the confirmed onboard charger
- Verify Mode 2, Mode 3 and stored-fault state
Rule out the cable and charge point without opening the car
Try a known-compatible cable and a second known-good AC charge point before opening the vehicle. Record whether both Mode 2 portable charging and Mode 3 wall charging fail in the same way. Inspect the connector and inlet for debris, heat damage, water, or a bent pin without touching energized contacts. Save the red-light sequence and number of lock attempts on video. If there is heat, odor, arcing, or physical damage, stop using the equipment. Do not use a DC fast-charge result to clear an AC onboard-charger path; they do not use every component identically.
Record the three lock attempts and inlet light
The three lock cycles are part of the evidence. Write the sequence second by second: plug inserted, proximity detected, lock motor operates, pin position changes, control pilot transitions, charge should begin, red indication appears. Save P33E8 and related charging, body, and high-voltage faults before cycling the ignition repeatedly. Note 12-volt battery condition, because the latch and control electronics rely on it. A clicking lock can be mechanically blocked, electrically weak, incorrectly reported, or functioning while another module misunderstands the state.
Map proximity, control pilot and lock position
Proximity tells the vehicle a plug is present and helps describe cable capability. The control-pilot duty and state coordinate availability and charging permission. The lock-position circuit tells the controller whether the plug is secured. Use Audi’s exact connector views, isolation state, and expected voltages; never assume public EVSE diagrams match the Q7 e-tron. Capture signals together when possible so their timing relationship is visible. The important question is not whether each wire has “some voltage” but whether the sequence advances at the correct moment.
Prove the pin moves before replacing the latch
Observe or measure pin movement through the approved service method while comparing the commanded and reported positions. Check for obstruction, alignment, motor supply, and end-position changes. In this case, the pin physically moved even though it repeated the attempt. That result weakened a jammed-latch theory. Do not apply external voltage to the motor to force a result unless the factory test plan explicitly permits it. A forced latch can damage the inlet or secure a connector in an unsafe state.
| Timeline point | Evidence to preserve |
|---|---|
| Plug inserted | Proximity state and physical fit |
| Lock commanded | Motor supply, pin movement, position voltage |
| Charge permission | Control-pilot transition and OBC reported state |
| Failure | Red indication, attempt count, P33E8 and companion faults |
Compare actual position with the OBC reading
Compare the actual low-voltage position signal at the relevant boundary with the value the onboard charger reports. If the voltage changes correctly as the pin reaches lock and unlock but the controller interprets the wrong state, the fault lies beyond the mechanical pin. Verify connector integrity and ground reference so a voltage drop is not blamed on module logic. The contradiction—working pin, valid change, invalid OBC state—was the turning evidence that justified onboard-charger replacement in the documented vehicle.
Keep low-voltage measurement outside the high-voltage zone
The onboard charger is connected to hazardous energy. Only appropriately trained technicians should depower, verify absence of voltage, establish equipotential bonding where required, and work under current Audi repair information. A general meter is not proof of safe isolation, and the orange harness is not a test area for exploratory probing. Keep the low-voltage capture and the high-voltage replacement as separately controlled jobs. If the diagnosis reaches the OBC without trained facilities, the correct action is a documented handoff, not a DIY continuation.
Replace and commission the confirmed onboard charger
Install the exact compatible OBC, complete cooling-system or refrigerant-related steps if the architecture requires them, and perform coding, parameterization, component protection, or basic settings. Inspect high- and low-voltage connectors before energizing. Restore the system through the formal sequence and rescan. Confirm that the lock-position values now change by the expected amount and that P33E8 does not immediately return. A new OBC that is not commissioned can create a new no-charge state unrelated to the original failure.
Verify Mode 2, Mode 3 and stored-fault state
Repeat both charging modes that failed. Watch the connector lock once, confirm the control pilot enters charging state, verify current flows, and allow enough energy transfer to demonstrate stability rather than stopping at “charging displayed.” Check inlet temperature, warnings, fault memory, and release of the connector at the end. The documented Q7 e-tron charged again and P33E8 stayed absent after OBC replacement. Record the EVSE used and starting state of charge so another technician can reproduce the proof.
The lock pin was loud, visible, and innocent. The decisive test compared what moved with what the OBC believed had moved. That distinction protected the owner from a latch replacement that would not restore charging. For any plug-in fault, make the handshake visible, keep low- and high-voltage work inside their qualifications, and verify with sustained energy transfer on the charging modes that originally failed.
